Nominal voltage(V)		36
Rated Capacity(Ah) (*1)		150
Energy capacity(kWh)		5.4
Maximum output(kW) (*2)	0.1sec	161
	10sec	96
Outline dimensions(mm)L x W x H (*3)		1371x223x345
Volume(L)		106
Weight(kg)		240
Energy density per unit volume(Wh/L)		51
Energy density per unit weight(Wh/kg)		23

* Specifications may change without notice.

*1  Recommended capacity will depend on operating conditions.

*2  Calculated from results of an I-V test of 0.1 sec discharge(0.6V/cell)

*3  Mounting hardware not included.
